VOLVO ECM Fault Codes
A complete list of engine control module (ECM) error codes for Volvo trucks. Here you will find DTC decodings, typical causes of malfunctions and recommendations for troubleshooting. The materials will help you quickly diagnose failures in the injection system, fuel equipment, sensors and electrical circuits. Useful for mechanics, service centers and owners of Volvo FH, FM, FL and other models of equipment.
Fault Codes EML4, EM-EU6/ECM VOLVO FH (4)
Diagnostic Trouble Code / DTC Name / Fault Type
P001676 Crankshaft Position - Camshaft Position Correlation
Incorrect Mounting Position
P003A99 Turbocharger/Turbocharger "A" Boost Control Position Exceeded
Learning Threshold
Parameter Learning Limit Exceeded
P004513 Turbocharger/Turbocharger "A" Boost Control Circuit Open
Open Circuit
P004519 Turbocharger/Turbocharger "A" Boost Control Circuit Open
Circuit Current Above Threshold
P004577 Turbocharger/Turbocharger "A" Boost Control Circuit Open
Desired Position Unattainable
P004591 Turbocharger/Turbocharger "A" Boost Control Circuit Open
Parametric
P004592 Boost Control Circuit Open Turbocharger/Turbocharger "A" Circuit
Performance or Malfunction
P00459A Turbocharger/Turbocharger "A" Boost Control Circuit Open
Component or System Operating Condition
P006964 Manifold Absolute Pressure and Barometric Pressure Correlation
Signal Plausibility Violation
P006E16 Turbocharger/Turbocharger "A" Boost Control Supply Voltage Circuit
Circuit Voltage Below Limit
P006E17 Turbocharger/Turbocharger "A" Boost Control Supply Voltage Circuit
Circuit Voltage Above Limit
P007011 Outside Air Temperature Sensor "A" Circuit Short to Ground
P007015 Outside Air Temperature Sensor "A" Circuit Short to Battery or Open
P008700 Fuel Rail/System Pressure Too Low, Bank 1
No subtype information available
P008800 Fuel Rail/System Pressure Too High, Bank 1
No subtype information available
P008A00 Low Pressure Fuel System Pressure Too Low
No subtype information available
P008B00 Low Pressure Fuel System Pressure Too High
No subtype information available
P008B97 Low Pressure Fuel System Pressure Too High
Component or system operation restricted or jammed
P009011 Fuel Pressure Regulator Control 1 Circuit Short to Ground
P009012 Fuel Pressure Regulator Control 1 Circuit Short to Battery
P009013 Fuel Pressure Regulator Control 1 Circuit Open
P009400 Fuel Leak Detected system - small leak
No subtype information available
P009A00 Engine Intake Air Temperature - Correlation
No subtype information available
P009B11 Fuel Pressure Relief Control Circuit Short to Ground
P009B12 Fuel Pressure Relief Control Circuit Short to Battery
P009B13 Fuel Pressure Relief Control Circuit Open
P009B73 Fuel Pressure Relief Control Actuator Stuck Closed
P00AF41 Turbocharger/Turbocharger Boost Control Module "A" Performance
Common Checksum Error
P00C600 Fuel Rail Pressure Too Low - Engine Rotation
No Subtype Information
P010501 Manifold Absolute Pressure/BARO Sensor
General Electrical Malfunction
P010512 Manifold Absolute Pressure/BARO Sensor
Circuit Short to Battery
P010513 Manifold Absolute Pressure/BARO Sensor Pressure Sensor
Open Circuit
P010562 Manifold Absolute Pressure/BARO Sensor
Signal Comparison Error
P011001 Intake Air Temperature Sensor 1 Bank 1 General Electrical
Fault
P011011 Intake Air Temperature Sensor 1 Bank 1 Circuit Short to Ground
P011013 Intake Air Temperature Sensor 1 Bank 1 Circuit Open
P011501 Engine Coolant Temperature Sensor 1
General Electrical
P011511 Engine Coolant Temperature Sensor 1
Circuit Short to Ground
P011513 Engine Coolant Temperature Sensor 1
Circuit Open
P01152A Engine Coolant Temperature Sensor 1
Signal Stuck in Range
P012011 Throttle/Pedal Position Sensor "A"
Circuit Short to ground
P012012 Throttle/Pedal Position Sensor "A"
Circuit Short to Battery
P012800 Coolant Thermostat (Coolant Temperature Below Thermostat
Setting Temperature)
No Subtype Information
P016800 Engine Fuel Temperature Too High
No Subtype Information
P016E00 Closed Loop Fuel Pressure Control Limit - Pressure Too High
No Subtype Information
P016F00 Closed Loop Fuel Pressure Control Limit - Pressure Too Low
No Subtype Information
P018501 Fuel Temperature Sensor "B" General Electrical Malfunction
P018511 Fuel Temperature Sensor "B" Circuit Short to Ground
P018513 Fuel Temperature Sensor "B" Circuit Open
P018564 Fuel Temperature Sensor "B" Plausibility Violation Signal
P019001 Fuel Rail Pressure Sensor Bank 1
General Electrical Malfunction
P019011 Fuel Rail Pressure Sensor Bank 1
Circuit Short to Ground
P019013 Fuel Rail Pressure Sensor Bank 1
Open Circuit
P019062 Fuel Rail Pressure Sensor Bank 1
Signal Comparison Error
P019064 Fuel Rail Pressure Sensor Bank 1
Signal Plausibility Error
P019511 Engine Oil Temperature Sensor "A" Circuit Short to Ground
P019513 Engine Oil Temperature Sensor "A" Circuit Open
P019564 Engine Oil Temperature Sensor "A" Signal Plausibility Error
P01B901 Engine Oil Temperature Sensor "B" General Electrical Malfunction
P01B911 Engine Oil Temperature Sensor "B" Circuit Short to Ground
P01B913 Engine Oil Temperature Sensor "B" Circuit Open
P020111 Cylinder 1 Injector "A" Circuit Short to Ground
P020112 Cylinder 1 Injector "A" Circuit Short to Battery
P020113 Cylinder 1 Injector "A" Circuit Open
P020156 Cylinder 1 Injector "A" Invalid/Incompatible Configuration
P020211 Cylinder 2 Injector "A" Circuit Short to Ground
P020212 Cylinder 2 Injector "A" Circuit Short to Battery
P020213 Cylinder 2 Injector "A" Open Circuit
P020256 Cylinder 2 Injector "A" Invalid/Incompatible Configuration
P020311 Cylinder 3 Injector "A" Short to Ground
P020312 Cylinder 3 Injector "A" Short to Battery
P020313 Cylinder 3 Injector "A" Open Circuit
P020356 Cylinder 3 Injector "A" Invalid/Incompatible Configuration
P020411 Cylinder 4 Injector "A" Short to Ground
P020412 Cylinder 4 Injector "A" Short to Battery
P020413 Cylinder 4 Injector "A" Open Circuit
P020456 Cylinder 4 Injector "A" Invalid/Incompatible Configuration
P020511 Cylinder 5 Injector "A" Circuit Short to Ground
P020512 Cylinder 5 Injector "A" Circuit Short to Battery
P020513 Cylinder 5 Injector "A" Circuit Open
P020556 Cylinder 5 Injector "A" Invalid/Incompatible Configuration
P020611 Cylinder 6 Injector "A" Circuit Short to Ground
P020612 Cylinder 6 Injector "A" Circuit Short to Battery
P020613 Cylinder 6 Injector "A" Circuit Open
P020656 Cylinder 6 Injector "A" Invalid/Incompatible configuration
P021700 Engine Coolant Temperature Overload Condition
No subtype information available
P021800 Transmission Oil Temperature Overload Condition
No subtype information available
P021900 Engine Speed Overload Condition
No subtype information available
P023400 Turbocharger/Supercharger Overboost Condition
No subtype information available
P024311 Turbocharger/Supercharger Wastegate Solenoid "A"
Circuit Short to Ground
P024312 Turbocharger/Supercharger Wastegate Solenoid "A"
Circuit Short to Battery
P024313 Turbocharger/Supercharger Wastegate Solenoid "A"
Circuit Open
P025612 Fuel Metering Pump B Circuit Short to battery voltage
P025614 Fuel Metering Pump B Circuit Short to Ground or Open
P025692 Fuel Metering Pump B Performance or Malfunction
P026A00 Charge Air Cooler Efficiency Below Limit
No subtype information available
P029800 Engine Oil Temperature Too High No subtype information available
P029900 Turbocharger/Supercharger Boost Low
No subtype information available
P02CC00 Cylinder 1 Fuel Injector - Detect Correction at Minimum Limit
No subtype information available
P02CD00 Cylinder 1 Fuel Injector - Detect Correction at Maximum Limit
No subtype information available
P02CE00 Cylinder 2 Fuel Injector - Detect Correction at Minimum Limit
No subtype information available none
P02CF00 Cylinder 2 Fuel Injector - Detect Correction at Maximum Limit
No subtype information available
P02D000 Cylinder 3 Fuel Injector - Detect Correction at Minimum Limit
No subtype information available
P02D100 Cylinder 3 Fuel Injector - Detect Correction at Maximum Limit
No subtype information available
P02D200 Cylinder 4 Fuel Injector - Detect Correction at Minimum Limit
No subtype information available
P02D300 Cylinder 4 Fuel Injector - Detect Correction at Maximum Limit
No subtype information available
P02D400 Cylinder 5 Fuel Injector - Detect Correction at Minimum Limit
No subtype information available
P02D500 Cylinder 5 Fuel Injector - Detect Correction at Maximum limit
No subtype information available
P02D600 Cylinder 6 Fuel Injector - Detection of Correction at Minimum Limit
No subtype information available
P02D700 Cylinder 6 Fuel Injector - Detection of Correction at Maximum Limit
No subtype information available
P02E011 Diesel Intake Air Flow Control
Circuit Short to Ground
P02E012 Diesel Intake Air Flow Control
Circuit Short to Battery
P02E013 Diesel Intake Air Flow Control
Circuit Open
P02E07C Diesel Intake Air Flow Control
Slow Response
P02E09B Diesel Intake Air Flow Control
High/Excessive Flow
P02E09C Diesel Intake Air Flow Control
Circuit Short to Engine
Low/Insufficient Flow
P02E601 Diesel Intake Air Flow Position Sensor
General Electrical Malfunction
P02E612 Diesel Intake Air Flow Position Sensor
Circuit Short to Battery
P02E613 Diesel Intake Air Flow Position Sensor
Open Circuit
P02E697 Diesel Intake Air Flow Position Sensor
Component or System Operation Restricted or Stuck
P02E699 Diesel Intake Air Flow Position Sensor
Parameter Detection Limit Exceeded
P03351F Crankshaft Position Sensor "A" Circuit Intermittent
P033531 Crankshaft Position Sensor "A" No Signal
P033538 Crankshaft Position Sensor "A" Incorrect Signal Frequency
P034031 Camshaft Position Sensor "A" Bank 1 or Single Sensor
No Signal
P034038 Camshaft Position Sensor "A" Bank 1 or Single Sensor
Incorrect Frequency Signal
P04007C Exhaust Gas Recirculation Flow "A" Slow Response
P04009B Exhaust Gas Recirculation Flow "A" High/Excessive Flow
P04009C Exhaust Gas Recirculation Flow "A" Low/Insufficient Flow
P040311 EGR Control "A" Circuit Short to Ground
P040312 EGR Control "A" Circuit Short to Battery
P040313 EGR Control "A" Circuit Open
P040341 EGR Control "A" General Checksum Error
P040371 EGR Control "A" Actuator Stuck
P040392 EGR Control "A" Performance or Malfunction
P040901 EGR Differential Pressure Sensor General Electrical Malfunction
P040912 EGR Differential Pressure Sensor Short to Battery
P040913 EGR Differential Pressure Sensor Open Circuit
P040964 EGR Differential Pressure Sensor Signal Plausibility Malfunction
P040A01 Exhaust Gas Recirculation Temperature Sensor "A"
General Electrical Malfunction
P040A11 Exhaust Gas Recirculation Temperature Sensor "A"
Short to Ground
P040A13 Exhaust Gas Recirculation Temperature Sensor "A"
Open Circuit
P040A64 Exhaust Gas Recirculation Temperature Sensor "A"
Signal Plausibility Malfunction
P041A11 Exhaust Gas Recirculation Temperature Sensor "B" Circuit
Short to Ground
P041A12 Exhaust Gas Recirculation Temperature Sensor "B" Circuit
Short to Battery
P041A2A Circuit Exhaust Gas Recirculation Temperature Sensor "B"
Signal Stuck in Range
P042000 Catalyst System Efficiency Below Threshold No Subtype Information
P047001 Exhaust Gas Pressure Sensor "A" General Electrical Malfunction
P047012 Exhaust Gas Pressure Sensor "A" Short to Battery
P047013 Exhaust Gas Pressure Sensor "A" Open Circuit
P047064 Exhaust Gas Pressure Sensor "A" Signal Plausibility Violation
P047511 Exhaust Gas Pressure Control Valve "A"
Short to Ground
P047512 Exhaust Gas Pressure Control Valve "A"
Short to Battery
P047513 Exhaust Gas Pressure Control Valve "A"
Open Circuit
P047572 Exhaust Gas Pressure Control Valve "A"
Actuator stuck open
P048011 Fan 1 Control Circuit Short to Ground
P048012 Fan 1 Control Circuit Short to Battery
P048013 Fan 1 Control Circuit Open
P048613 EGR Sensor "B" Open Circuit
P049D99 EGR Control Position "A" Exceeded Learning Limit
Parameter Detection Limit Exceeded
P04D900 EGR Closed Loop Control At Limit - Flow Too Low
No Subtype Information
P04DA00 EGR Closed Loop Control At Limit - Flow Too High
No Subtype Information
P050011 Vehicle Speed Wheel Circuit Short to Ground
P050013 Vehicle Speed Wheel Circuit Open
P051A01 Crankcase Pressure Sensor General Electrical Malfunction
P051A12 Crankcase Pressure Sensor Circuit Short to Battery
P051A13 Crankcase Pressure Sensor Circuit Open
P051A64 Crankcase Pressure Sensor Signal Plausibility Violation
P052001 Engine Oil Pressure Switch/Switch "A" General Electrical Malfunction
P052012 Engine Oil Pressure Switch/Switch "A" Circuit Short to Battery
P052013 Engine Oil Pressure Switch/Switch "A" Circuit Open
P052064 Engine Oil Pressure Switch/Switch "A" Signal Plausibility Violation
P052400 Engine Oil Pressure - Too Low Engine oil pressure - too low
P052607 Fan Speed Sensor Circuit Mechanical Malfunctions
P052612 Fan Speed Sensor Circuit Short to Battery
P053E00 Engine Oil Pressure Crankcase - Too High No Subtype Information
P054001 Intake Air Heater Control "A" General Electrical Malfunction
P054011 Intake Air Heater Control "A" Circuit Short to Ground
P054013 Intake Air Heater Control "A" Circuit Open
P054070 Intake Air Heater Control "A" Actuator Stuck On
P05407F Intake Air Heater Control "A" Actuator Stuck Off
P054464 Exhaust Gas Temperature Sensor - Bank 1 Sensor 1
Signal Plausibility Violation
P055A01 Engine Oil Pressure Switch/Switch "B" General Electrical Malfunction
P055A12 Engine Oil Pressure Switch/Switch "B" Circuit Short to Battery
P055A13 Engine Oil Pressure Switch/Switch "B" Open circuits
P055A64 Engine Oil Pressure Sensor/Switch "B" Signal Plausibility Violation
P055F00 Engine Oil Pressure Out of Range No subtype information available
P05E311 Parking Brake Switch/Switch Circuit Short to Ground
P05E362 Parking Brake Switch/Switch Circuit Signal Compare Error
P05E364 Parking Brake Switch/Switch Circuit Signal Plausibility Violation
P061511 Starter Relay Circuit Short to Ground
P061512 Starter Relay Circuit Short to Battery
P061513 Starter Relay Circuit Open
P06279C Fuel Pump Control "A" Low/Insufficient Flow
P064111 Sensor Reference Voltage "A" Circuit Short to Ground
P064112 Sensor Reference Voltage "A" Circuit Short to Battery
P06411C Sensor "A" Reference Voltage Circuit Out of Voltage Range
P065111 Sensor "B" Reference Voltage Circuit Short to Ground
P066601 Control Module "A" Internal Temperature Sensor
General Electrical Malfunction
P066611 Control Module "A" Internal Temperature Sensor
Circuit Short to Ground
P06B016 Sensor "A" Supply Voltage Circuit Below Threshold
P06B017 Sensor "A" Supply Voltage Circuit Above Threshold
P06B316 Sensor "B" Supply Voltage Circuit Below Threshold
P06B317 Sensor "B" Supply Voltage Circuit Above Threshold
P06DA71 Engine Oil Pressure Regulation Actuator Stuck
P06E616 Sensor "C" Supply Voltage Circuit Below threshold
P06E617 Sensor "C" Supply Voltage Circuit Voltage Above Threshold
P073021 Recommended Gear Signal Amplitude Less Than Minimum
P073022 Recommended Gear Signal Amplitude Above Maximum
P07307C Recommended Gear Slow Response
P100101 Engine Stop Switch General Electrical Malfunction
P100111 Engine Stop Switch Circuit Short to Ground
P100112 Engine Stop Switch Circuit Short to Battery
P100190 Engine Stop Switch Stuck Open
P100192 Engine Stop Switch Performance or Malfunction
P100211 Heater Relay Circuit Short to Ground
P100212 Heater Relay Circuit Short to Battery
P100213 Engine Stop Switch Circuit Short to Preheater Circuit Open
P100701 Air Cleaner Indicator General Electrical Malfunction
P100711 Air Cleaner Indicator Circuit Short to Ground
P100712 Air Cleaner Indicator Circuit Short to Battery
P100713 Air Cleaner Indicator Circuit Open
P101711 Fuel Water Drain Valve Circuit Short to Ground
P101E11 Transmission Full Lock Valve Circuit Short to Ground
P101E12 Transmission Full Lock Valve Circuit Short to Battery
P101E13 Transmission Full Lock Valve Circuit Open
P102111 Volvo Compression Brake (VCB) Control Circuit
Short to Ground
P102112 Volvo Compression Brake (VCB) Control Circuit
Short to Battery
P102113 Volvo Compression Brake (VCB) Control Circuit
Open circuits
P108600 Oil level moderately low No subtype information available
P109300 Engine oil pressure moderately low No subtype information available
P10C011 Volvo Compression Brake (VCB) Control Circuit "2"
Circuit Short to Ground
P10C012 Volvo Compression Brake (VCB) Control Circuit "2"
Circuit Short to Battery
P10C013 Volvo Compression Brake (VCB) Control Circuit "2"
Open Circuit
P10E100 Diesel Particulate Filter (DPF) Pressure Shift Critically High
No subtype information available
P10E200 Diesel Particulate Filter (DPF) Pressure Shift Moderately High
No subtype information available
P10F800 Air Filter Clogged No subtype information available
P10FE00 Particulate Filter Clogged - Soot Buildup Moderate High - Bank 1
No subtype information available
P110400 Factory Mode No subtype information available
P110501 Engine Rear Start Switch "A" Circuit General Electrical Malfunction
P110511 Engine Rear Start Switch "A" Circuit Short to Ground
P110512 Engine Rear Start Switch "A" Circuit Short to Battery
P110573 Engine Rear Start Switch "A" Circuit Actuator Stuck Closed
P111600 Manifold Absolute Pressure Sensor - Moderate High
No subtype information available
P111800 Manifold Absolute Pressure Sensor - High High
No subtype information available
P111945 Intake Manifold Temperature Too High at Moderate Level
Memory Failure
P111A00 Intake Manifold Temperature Too High
No subtype information available
P111D00 Engine Coolant Level Moderately Low
No subtype information available
P111E00 Engine Coolant Temperature Moderately High
No subtype information available
P112500 Engine Oil Temperature Moderately High
No subtype information available
P112800 Piston Cooling Oil Pressure Moderately Low
No subtype information available
P112900 Transmission Oil Temperature Moderately High
No subtype information available
P112B00 Turbocharger/Turbocharger "A" Actuator Temperature Too High
No subtype information available
P112E00 Exhaust Gas Temperature Moderately High - Bank 1
No subtype information available
P113411 Exhaust Aftertreatment Fuel Injection Air Purge Valve gases
Circuit short to ground
P113413 Aftertreatment fuel injection purge air valve
Circuit open
P113472 Aftertreatment fuel injection purge air valve
Actuator stuck open
P113473 Aftertreatment Fuel Injection Air Purge Valve
Actuator Stuck Closed
P113500 Crankcase Pressure Too High Relative to Atmospheric
No Subtype Information
P113600 NOx Sensor 1/2 Correlation Calibration Error - Bank 1
No Subtype Information
P113711 Oil Thermostat Circuit Short to Ground
P113712 Oil Thermostat Circuit Short to Battery
P113713 Oil Thermostat Circuit Open
P113F11 Buffered Idle Confirm Switch Wire - VECU Side
Circuit Short to Ground
P113F12 Buffered Idle Confirm Switch Wire - VECU Side
Circuit Short to Voltage Battery
P114000 Volvo Compression Brake Control (VCB) - Oil Temperature Too Low
No Subtype Information
P114101 Buffered Idle Confirmation Switch Wire - ECM Side
General Electrical Malfunction
P114113 Buffered Idle Confirmation Switch Wire - ECM Side
Open Circuit
P114123 Buffered Idle Confirmation Switch Wire - ECM Side
Continuously Low Voltage
P114124 Buffered Idle Confirmation Switch Wire - ECM Side
Continuously High Voltage
P114411 Starter Relay High Side Circuit Short to Ground
P114412 Starter Relay High Side Circuit Short to Battery
P114413 Starter Relay High Side Circuit Open
P114500 Voltage Level Reductant Moderately Low No subtype information available
P114700 Fuel Rail/System Pressure Bank 1 - Moderately Too High
No subtype information available
P114B00 Turbocharger/Turbocharger "A" Actuator Temperature Too Low
No subtype information available
P114E00 EGR Actuator Temperature Out of Operating Range No subtype information available
P115000 Throttle/Pedal Position Sensor/Switch "A"/"D" Voltage Correlation
No subtype information available
P115100 Aftertreatment System Temperature High No subtype information available
P115211 Starting Fuel Pump Circuit Short to Ground
P115212 Starting Fuel Pump Circuit Short to Battery
P115213 Starting Fuel Pump Open circuits
P115400 Body Control Module "A" Lost Communication with Instrument Cluster (IPC) Control Module
No subtype information available
P117311 Transmission Low Range Authorization Valve
Circuit Short to Ground
P117312 Transmission Low Range Authorization Valve
Circuit Short to Battery
P117313 Transmission Low Range Authorization Valve
Open Circuit
P117401 Transmission Range Request General Electrical Malfunction
P117411 Transmission Range Request Circuit Short to Ground
P117412 Transmission Range Request Circuit Short to Battery
P117600 Starter Motor Disabled - Over Temperature
No subtype information available
P117700 Starter Motor Disabled - Transmission Not in Neutral
Subtype information available none
P117800 Starter Motor Disabled - Starter Motor and Engine Gear
Jammed
No Subtype Information
P117900 Starter Motor Disabled - Power Take-Off Active
No Subtype Information
P117B01 Engine Compartment Temperature Sensor Switch
General Electrical Malfunction
P117B11 Engine Compartment Temperature Sensor Switch
Circuit Short to Ground
P117B12 Engine Compartment Temperature Sensor Switch
Circuit Short to Battery
P117C00 Driver Requested Gear Range Too High
No Subtype Information
P117D00 Driver Requested Gear Too Low
No Subtype Information
P117E00 Driver Requested Start Gear Too High
No Subtype Information
P117F11 Bypass Valve Hydraulic Fan Circuit Short to Ground
P117F12 Hydraulic Fan Bypass Valve Circuit Short to Battery
P117F13 Hydraulic Fan Bypass Valve Circuit Open
P203164 Exhaust Gas Temperature Sensor - Bank 1 Sensor 2
Signal Plausibility Violation
P203A86 Reagent Level Sensor "A" Invalid Signal
P203F00 Reductant Level Low No Subtype Information
P204F93 SCR System Performance - Dosing Failure Inoperative
P207F9A Reductant Quality Component or System Operating Conditions
P20D711 Aftertreatment Fuel Control
Circuit Short to Ground
P20D713 Aftertreatment Fuel Control
Circuit Open
P20D773 Aftertreatment Fuel Control
Actuator Stuck Closed
P20DD01 Aftertreatment Fuel Pressure Sensor
General Electrical Malfunction
P20DD12 Aftertreatment Fuel Pressure Sensor
Circuit Short to Battery
P20DD13 Aftertreatment Fuel Pressure Sensor
Circuit Open
P20EE00 SCR NOx Catalyst Efficiency Below Limit (Bank 1)
Subtype Information none
P20F400 AdBlue Consumption Too Low No Subtype Information
P20F500 Reductant Consumption Too High No Subtype Information
P210900 Throttle/Pedal Position Sensor "A" Minimum Limiter Performance
No Subtype Information
P213600 Throttle/Pedal Position Sensor/Switch "A"/"C" Voltage Correlation
No Subtype Information
P215A62 Vehicle Speed to Wheel Speed Correlation
Signal Comparison Error
P215A64 Vehicle Speed to Wheel Speed Correlation
Signal Plausibility Violation
P216300 Throttle/Pedal Position Sensor "A" Maximum Limiter Performance
No Subtype Information
P220012 NOx Sensor - Bank 1 Sensor 1 Circuit Short to Voltage Battery
P220013 NOx Sensor Bank 1 Sensor 1 Open Circuit
P22001C NOx Sensor Bank 1 Sensor 1 Circuit Out of Voltage Range
P220064 NOx Sensor Bank 1 Sensor 1 Signal Plausibility Failure
P220093 NOx Sensor Bank 1 Sensor 1 No Function
P222601 BARO Circuit General Electrical Failure
P222612 BARO Circuit Short to Battery
P222613 BARO Circuit Open Circuit
P222664 BARO Circuit Plausibility Failure
P225C00 NOx Sensor Performance - Signal Stuck High - Bank 1 Sensor 1
No Subtype Information
P225D00 NOx Sensor Performance - Signal Stuck Low - Bank 1 Sensor 1
No subtype information available
P225E67 NOx Sensor Performance - Signal Stuck High - Bank 1 Sensor 2
Invalid Signal After Event
P225F00 NOx Sensor Performance - Signal Stuck Low - Bank 1 Sensor 2
No subtype information available
P226401 Water in Fuel Sensor General Electrical Malfunction
P226411 Water in Fuel Sensor Circuit Short to Ground
P226413 Water in Fuel Sensor Circuit Open
P228D72 Fuel Pressure Regulator 1 Exceeded Control Limits - Pressure Too High
Actuator Stuck Open
P228E00 Fuel Pressure Regulator 1 Exceeded Learning Limits - Pressure Too Low
No subtype information available
P228F00 Fuel Pressure Regulator 1 Exceeded Learning Limits - Pressure Too High
Subtype information available missing
P229E12 NOx Sensor Bank 1 Sensor 2 Short to Battery Voltage
P229E13 NOx Sensor Bank 1 Sensor 2 Open Circuit
P229E1C NOx Sensor Bank 1 Sensor 2 Out of Voltage Range Circuit
P229E64 NOx Sensor Bank 1 Sensor 2 Signal Plausibility Violation
P229E93 NOx Sensor - Bank 1 Sensor 2 Inoperative
P22FB92 NOx Sensor Performance - Sensing Element - Bank 1 Sensor 1
Performance or Malfunction
P22FE00 NOx Sensor Performance - Sensing Element - Bank 1 Sensor 2
No Subtype Information Available
P242800 Exhaust Gas Temperature Too High No Subtype Information Available
P242A64 Exhaust Gas Temperature Sensor - Bank 1 Sensor 3
Signal Plausibility Violation
P244A00 Diesel Particulate Filter Aftertreatment 1 Differential Pressure Too Low (Bank 1)
No Subtype Information Available
P244B00 Diesel Particulate Filter Aftertreatment 1 Differential Pressure Too High (Bank 1)
No Subtype Information Available
P244C00 Exhaust Gas Temperature Too Low for DPF Regeneration (Bank 1)
No subtype information available
P245264 Diesel Particulate Filter "A" Pressure Sensor Signal Plausibility Violation
P245700 EGR Cooler Efficiency Below Threshold
No subtype information available
P246300 Diesel Particulate Filter Clogged - Soot Buildup - Bank 1
No subtype information available
P249D00 Closed Loop Reductant Injection Control At Limit - Flow Too
Small
No subtype information available
P249E00 Closed Loop Reductant Injection Control At Limit - Flow Too
High
No subtype information available
P249F92 Excessive Time to Enter Closed Loop Regeneration Control of Diesel Particulate Filter
Performance or Malfunction
P24A000 DPF Regeneration Control Closed Loop At Limit - Temperature Too Low
No subtype information available
P24A100 DPF Regeneration Control Closed Loop At Limit - Temperature Too High
No subtype information available
P24A200 Diesel Particulate Filter Regeneration Not Complete (Bank 1)
No subtype information available
P24A400 Diesel Particulate Filter Clogged - Soot Buildup Too Large (Bank 1)
No subtype information available
P250A11 Engine Oil Level Sensor Circuit Short to Ground
P250A13 Engine Oil Level Sensor Circuit Open
P250F00 Engine Oil Level Too Low No subtype information available
P253901 Low Fuel Pressure Sensor Circuit General Electrical Malfunction
P253912 Low Fuel Pressure Sensor Circuit Short to voltage
battery
P253913 Low Pressure Fuel System Sensor Circuit Open Circuit
P255601 Engine Coolant Level Sensor/Switch
General Electrical Malfunction
P255611 Engine Coolant Level Sensor/Switch
Circuit Short to Ground
P255612 Engine Coolant Level Sensor/Switch
Circuit Short to Battery Voltage
P255613 Engine Coolant Level Sensor/Switch
Circuit Open
P256000 Engine Coolant Level - Low
No Subtype Information
P256214 Turbocharger Boost Control Position Sensor "A"
Circuit Short to Ground or Open
P256214 Turbocharger Boost Control Position Sensor "A"
Circuit Short to Ground or Open
P259C00 Excessive Time to Enter Boost Control Turbocharger "A" Closed
Loop
No Subtype Information
P25A911 Piston Cooling Oil Control
Circuit Short to Ground
P25A912 Piston Cooling Oil Control
Circuit Short to Battery
P25A913 Piston Cooling Oil Control
Circuit Open
P25A971 Piston Cooling Oil Control
Actuator Stuck
P25AE00 Piston Cooling Oil Pressure Too Low
No Subtype Information
P260011 Coolant Pump Control Circuit/Open
Circuit Short to Ground
P260012 Coolant Pump Control Circuit/Open
Circuit Short to Battery
P260013 Coolant Pump Control Circuit/Open
Circuit Open
P268111 Engine Coolant Bypass Valve "A" Control
Circuit Short to Ground
P268112 Engine Coolant Bypass Valve "A" Control
Circuit Short to Battery
P268113 Engine Coolant Bypass Valve "A" Control
Circuit Open
P269711 Aftertreatment Fuel Injector "A" Aftertreatment Fuel Injector
Short to Ground
P269713 "A" Aftertreatment Fuel Injector
Open Circuit
P269773 "A" Aftertreatment Fuel Injector
Actuator Stuck Closed
P26977A "A" Aftertreatment Fuel Injector
Fluid Leak or Seal Fault
P2A1612 Fuel Flow Meter Control "D" (Cam/Rotor/Injector)
Short to Battery Voltage
P2A1614 Fuel Flow Meter Control "D" (Cam/Rotor/Injector)
Short to Ground or Open Circuit
P2A1692 Fuel Flow Meter Control "D" (Cam/Rotor/Injector)
Characteristics or malfunction
P2A1E12 Fuel injection pump flow meter "F" control (Cam/Rotor/Injector)
Circuit short to battery
P2A1E14 Fuel injection pump flow meter "F" control (Cam/Rotor/Injector)
Circuit short to ground or open
P2A1E92 Fuel injection pump flow meter "F" control (Cam/Rotor/Injector)
Characteristics or malfunction
U000188 CAN Communication network trunk bus 2
Bus disabled
U001088 CAN Communication network trunk bus 1
Bus disabled
U008088 Vehicle engine communication subnet Bus disabled
U010100 Lost Communication with TECU No subtype information available
U010A00 Lost Communication with Exhaust Gas Recirculation Module A
No subtype information available
U010C00 Lost Communication with Turbocharger/Supercharger Control Module A
No subtype information available
U012100 Lost Communication with Anti-lock Brake System (ABS) Control Module
No subtype information available
U012900 Lost Communication with Brake Control Module
No subtype information available
U014100 Lost Communication with VMCU No subtype information available
U014200 Lost Communication with Body Control Module "B" No subtype information available
U015500 Lost Communication with Instrument Cluster Control Module (IPC)
No subtype information available missing
U016700 Communication with vehicle immobilizer control module lost
Subtype information missing
U029D00 Communication with NOx sensor "A" lost
U029E00 Communication with NOx sensor "B" lost
U032300 Software incompatibility with instrument cluster control module
Subtype information missing
U033100 Software incompatibility with body control module "A"
Subtype information missing
U042600 Invalid data received from vehicle immobilizer control module
Subtype information missing
U116600 Communication with CIOM lost
Subtype information missing
U116900 Communication with DACU lost
Subtype information missing
U116B00 Communication with TCM lost via high speed communication bus CAN
No subtype information available
U116C00 Communication with TCM via Powertrain CAN Bus is Lost
No subtype information available
U116F00 Communication with Reductant Control Module via Engine Subnetwork is Lost
No subtype information available
U117100 Communication with Body Control Module via High Speed
Communication CAN Bus is Lost
No subtype information available
U117300 Communication with IPC control unit via high speed CAN communication bus is lost
Subtype information is missing
U117888 Vehicle powertrain CAN communication bus
Bus is disabled
U1FFF68 Factory mode is active Event details
U300001 Electronic control module General electrical fault
U300041 Electronic control module General checksum error
U300044 Electronic control module Data memory fault
U300045 Electronic control module Program memory fault
U300049 Electronic control module Internal electronics fault
U300257 Vehicle identification number Invalid/incompatible software component
